Fuel tank trailer Truckik

FOB Price:


Price range: $16,500-$28,500 due to different Specs.

I want a .


  • Max Safety: top protection rail to protect operators, anti-explosion manhole cover options to assure the safety;
  • Efficiency: powerful unloading system to achieve max unloading efficiency;
  • Light design: high tensile steel material and advanced design to achieve lower weight with high carrying capacity;
  • Surface treatment: zinc-rich-primer and polyurethane topcoat as customers’ choices;
  • Options: Carbon steel, Stainless steel, Aluminum tank options, 25 m3 – 60 m3 capacity available, 1-9 compartments, anti-overfill system, bottom loading system optional.

Fuel tank trailer Truckik

Dimension: Length: 12,000mm Width: 2,500mm Height: 3800mm

Kingpin location: 500mm from the front face of the front bolster

Axle spacer: 7,500mm+1,400mm

Landing gear location: 2,500mm behind the kingpin location

(The above dimension will be adjusted according to the tractor specification)

Payload: 29,400kg

Tare weight: Approx. 10,600kg

G.V.W.R: Approx. 40,000kg

Tank Volume:42,000L +5% Vapor

Tank body Material Q235 carbon steel; Tank head thickness 4mm. Tank shell thickness 3mm

Discharge valve:3” ball valve, 2pcs.

Manhole: Safety manhole with breath valve, 2pcs.

Bottom valve: Equipped aluminum bottom valve, pneumatic control, 1pcs.

Welding standard: All welding is to be done by a qualified welder per applicable national standard.

Painting: Shot blast at SA 2.5 prior to application of primer, polyurethane top coat. Total DFT not less than 100um.

Kingpin: JOST 2″ kingpin changeable.

Suspension: Suspension with leaf spring.

Axle:13-ton capacity, 3pcs, China.

Brake system: Dual line pneumatic brake, with ABS system

Brake chamber: Target type 30/30 spring brake system on 2 axles, China.

Air tank: 40L, 2 pcs, China.

Emergency relay valve: WABCO; China.

Rim: 9.0 -22.5 steel wheel, 10 holes ISO, 12 pcs. China.

Tire: Triangle brand 12R22.5, 12 pcs. China.

Landing gear: JOST brand.

Voltage: 24 Volt.

Receptacle:7-way socket, China.

Front marker Lamp: LED lamp. Including Front marker Lamp; Side marker lamp; Turn signal lamp; Rear lamp.

Reflector: Triangle reflector, red color.

Wiring: Electric cable protected by PVC conduit on main frame.

Fire extinguisher: 2 units per trailer.

Mud guard: Steel mud guard.

Spare wheel carriers:1 pc.

Tool box: 1 pc.

Why choose Truckik?


To lower the price, we manage to reduce costs, especially the marketing costs, but never reduce the quality.


We manage to provide the most cost-effective truck trailers, reliable quality will earn more profits for their owner.


With advanced manufacturing equipment and skilled workers, we can provide high quality truck trailers continuously.


Our trailers are highly customizable, we will offer professional design drawing to confirm order.
